Data Export

Overview

After conducting interviews using Interviewer or Fresco, you need to export the data for analysis. Network Canvas provides flexible export options that allow you to export data in formats compatible with statistical software, network analysis programs, and spreadsheet applications.

The export process transforms your interview data—including ego attributes, alter attributes, and edge data—into structured files that you can import into analysis tools such as R, Python, SPSS, UCINET, Gephi, and many others.

Where to export from

This page describes what Network Canvas exports contain, regardless of which application produced them. The steps for actually running an export differ by application — Interviewer and Interviewer Classic store data on the device and export it as files you keep, while Fresco stores data centrally and exports from its dashboard. Each application's own guide walks through its export workflow:

• Interviewer — see Using Interviewer
• Interviewer Classic — see Interviewer Online and Offline Workflows
• Fresco — see Using Fresco

File types

Network Canvas supports two file formats for data export. Choose the format that best suits your analysis needs.

CSV format

What it is: Comma-Separated Values (CSV) files are plain text files that represent tabular data. The CSV export creates multiple files, one for each type of entity in your network data, and complies with the egor package standard.

Best for:

• Statistical analysis in R, Python, SPSS, Stata, SAS
• Spreadsheet applications (Excel, Google Sheets, LibreOffice Calc)
• The egor package in R
• Custom data processing workflows

What you get:

The CSV export creates separate files for each entity type in your protocol:

Ego attribute list

• One row per ego (participant)
• Filename format: caseID_sessionUUID_ego.csv
• Contains:
  • Ego-level variables you collected
  • Session metadata (start time, finish time, protocol name, etc.)
  • Network Canvas identifiers (ego UUID, case ID, session ID)

Example structure:

ego_id,networkCanvasEgoUUID,networkCanvasCaseID,age,gender,sessionStart,sessionFinish
1,abc123-def456,case_001,34,Male,2025-01-15 10:30,2025-01-15 11:15
2,ghi789-jkl012,case_002,28,Female,2025-01-15 14:00,2025-01-15 14:45

Alter attribute list

• One row per alter (nominated node)
• Filename format: caseID_sessionUUID_attributeList_alterType.csv
• Contains:
  • All alter attributes you collected
  • Network Canvas identifiers (alter UUID, ego UUID)
  • Export-specific incrementing ID (unique only within this export)

Example structure:

ego_id,alter_id,networkCanvasUUID,networkCanvasEgoUUID,name,age,close_friend,contact_frequency
1,1,xyz789,abc123-def456,John,32,true,Daily
1,2,uvw456,abc123-def456,Sarah,29,true,Weekly
2,1,rst123,ghi789-jkl012,Michael,31,false,Monthly

Important notes:

• If your protocol defines multiple node types (e.g., "Person" and "Organization"), you'll receive a separate file for each type
• The alter_id is an incrementing integer unique only within each ego's network and this specific export
• The networkCanvasUUID is the permanent unique identifier for each alter

Edge attribute list

• One row per edge (relationship between alters)
• Filename format: caseID_sessionUUID_edgeList_edgeType.csv
• Contains:
  • Edge attributes you collected
  • Source and target identifiers (both UUID and export ID)
  • Link to ego network (networkCanvasEgoUUID)

Example structure:

ego_id,edge_id,edge_type,from,to,networkCanvasSourceUUID,networkCanvasTargetUUID,relationship_strength,frequency
1,1,friendship,1,2,xyz789,uvw456,strong,high

Important notes:

• The from and to columns reference the alter_id from the alter attribute list
• Multiple edge types create separate files
• Empty edge files are created even if no edges were collected

GraphML format

What it is: GraphML is an XML-based open standard for representing graph data. It stores the complete network structure in a single file.

Best for:

• Network visualization software (Gephi, NodeXL, Visone)
• Network analysis programs (UCINET, Pajek, ORA)
• Graph databases and tools that work with graph structures
• Preserving the complete network structure in one file

What you get:

• One file per interview session
• Filename format: caseID_sessionUUID.graphml
• Contains:
  • Complete network structure (nodes and edges)
  • All node and edge attributes
  • Ego attributes (stored as graph-level attributes)

Example structure:

<?xml version="1.0" encoding="UTF-8"?>
<graphml xmlns="http://graphml.graphdrawing.org/xmlns">
  <graph id="G" edgedefault="undirected">
    <node id="alter_1">
      <data key="name">John</data>
      <data key="age">32</data>
    </node>
    <node id="alter_2">
      <data key="name">Sarah</data>
      <data key="age">29</data>
    </node>
    <edge source="alter_1" target="alter_2">
      <data key="relationship_strength">strong</data>
    </edge>
  </graph>
</graphml>

Network Canvas GraphML extensions

Exported GraphML files include a small set of Network Canvas extensions so that interview metadata—such as the protocol used, case ID, and session identifiers—travels with the network data. These extensions are designed for interoperability: GraphML parsers that don't recognize them will simply ignore them.

Session metadata: Namespaced nc: attributes on the <graph> element store session-level metadata:

• nc:caseId
• nc:sessionUUID
• nc:protocolName
• nc:protocolUID
• nc:codebookHash
• nc:sessionExportTime
• nc:sessionStartTime
• nc:sessionFinishTime

The schema nc-types.xsd defines these attributes, and graphml+netcanvas.xsd extends the <graph> element to include them.

Ego attributes: Ego data is stored using the standard GraphML mechanism for attaching data to the graph itself, so no schema extension is needed. Each ego attribute is declared with a <key> element whose for attribute is set to graph, rather than node or edge:

<key id="ego_attribute" attr.name="ego_attribute" attr.type="string" for="graph" />

Note that the <key> element must be located outside of the <graph> element. The attribute is then given a value anywhere inside the <graph> element:

<graph>
  <data key="ego_attribute">Jimbo</data>
</graph>

Because this uses the existing GraphML schema, other parsers either ignore ego data or correctly display it as one or more attributes of the graph itself. Network Canvas parsers treat all graph-level <key> and <data> elements as describing ego.

Choosing between CSV and GraphML

Our recommendation: Export data in both formats when first working with Network Canvas data. This allows you to experiment and determine which format works best with your analysis workflow.

Export options

Network Canvas provides several specialized export options that affect how your data is formatted. You can usually leave these at their default values unless you have specific requirements.

Merge sessions by protocol

This option combines all interview sessions conducted with the same protocol into a single file (or set of files for CSV).

Availability: This option is only available in Interviewer Classic, up to version 6.5—it was removed in version 6.6. Interviewer and Fresco always export each session as separate files—Interviewer packages them into a single .zip archive for download.

When enabled, this creates one combined file per protocol containing all interviews. For CSV exports, you get a single ego file, a single alter file per type, and a single edge file per type. For GraphML exports, you get a single file containing a separate <graph> element for each session—note that most software outside Network Canvas does not support GraphML files with multiple graphs. When disabled, the export creates separate files for each interview session.

Enable this option when you want all your data in one place for analysis, or when you're importing into statistical software that works better with combined datasets. Disable it when you want to analyze individual interviews separately, or when you're doing quality checks on individual interviews.

If your application doesn't offer this option, you can combine the per-session CSV files during analysis instead—for example with dplyr::bind_rows in R.

Even when merged, ego networks remain separate—the data is combined into shared files, but network boundaries are preserved through the ego identifiers.

Use screen layout coordinates

This option adds screen-specific pixel coordinates alongside the normalized node positions recorded by Sociogram interfaces.

Network Canvas stores node positions from Sociogram layout variables as normalized x/y coordinates (values between 0 and 1) with the origin at the top-left. This normalization allows layouts to be displayed on screens of different sizes while maintaining relative positions.

A layout variable is exported as two CSV columns named after the variable, with _x and _y suffixes—a layout variable named layout produces layout_x and layout_y columns containing the normalized values. When this option is enabled, the export keeps those normalized columns and adds two further columns, layout_screenSpaceX and layout_screenSpaceY, containing pixel values (rounded to two decimal places) based on a screen size. In Interviewer, it uses the screen layout width and height you set in Settings → Data export (default 1920 x 1080 pixels). In Interviewer Classic, it uses the screen dimensions configured in its export settings, which default to — and can be reset to — the device's own resolution. In Fresco, it uses a fixed size of 1920 x 1080 pixels. When disabled (the default), only the normalized 0-1 columns are exported. Note that the screen-space Y value is calculated as (1 − y) × screen height, so it is measured from the bottom of the screen—matching the coordinate convention of most visualization software—while the normalized _y column is measured from the top.

Enable this option when you want to recreate the exact visual layout as it appeared during the interview, when you're importing into visualization software that expects pixel coordinates, or when you need coordinates that match specific screen dimensions. Disable it when you want device-independent coordinates that work on any canvas size, when you're comparing layouts created on different screen sizes, or when you want maximum flexibility for visualization.

Example:

Normalized (default), for a layout variable named layout:

nodeID,name,layout_x,layout_y
1,John,0.25,0.33
2,Sarah,0.75,0.67

With screen layout coordinates enabled (1920x1080):

nodeID,name,layout_x,layout_y,layout_screenSpaceX,layout_screenSpaceY
1,John,0.25,0.33,480.00,723.60
2,Sarah,0.75,0.67,1440.00,356.40

Additional export considerations

Unique identifiers: Network Canvas generates unique identifiers (UUIDs) for all entities:

• networkCanvasEgoUUID - Unique ego identifier across all sessions
• networkCanvasUUID - Unique alter identifier
• networkCanvasCaseID - Case identifier you provided or auto-generated
• networkCanvasSessionID - Unique session identifier

These identifiers allow you to:

• Merge data from multiple exports
• Link data to external sources
• Track participants across multiple interview sessions (if applicable)

Session metadata: Ego files include valuable metadata:

• sessionStart - Interview start timestamp
• sessionFinish - Interview end timestamp
• sessionExported - Export timestamp
• networkCanvasProtocolName - Protocol used

Data structure details

For a complete reference showing how each variable type is encoded in these files—column naming, value formats, and missing-value handling—see the Export Data Dictionary.

Understanding the ego-alter-edge structure

Network Canvas organizes personal network data using a standard ego network structure:

Ego (participant)
├── Alter 1 (network member)
├── Alter 2 (network member)
├── Alter 3 (network member)
└── Edges (relationships between alters)
    ├── Alter 1 → Alter 2
    └── Alter 2 → Alter 3

Ego level: One row per participant, containing:

• Participant demographics
• Aggregated network measures (if calculated)
• Session metadata

Alter level: Multiple rows per participant (one per nominated alter), containing:

• Alter attributes
• Ego-alter tie attributes
• Reference to ego (ego_id or networkCanvasEgoUUID)

Edge level: Relationships between alters within each ego network, containing:

• Edge attributes
• Source and target alter references
• Reference to ego network

Working with multiple entity types

If your protocol defines multiple node types (e.g., "Person" and "Place"), the export structure reflects this:

CSV export:

• Separate alter files: case_001_session_123_attributeList_Person.csv and case_001_session_123_attributeList_Place.csv
• Each file contains only alters of that specific type
• Edges between different types appear in the edge files with appropriate type indicators

GraphML export:

• All node types in one file
• Node type identified by attribute

Handling missing data

Network Canvas handles missing data as follows:

CSV format:

• Optional fields left blank: Empty cell
• Boolean variables not answered: Empty cell
• Multi-select checkboxes not selected: FALSE or empty

GraphML format:

• Optional attributes without values: Attribute tag omitted
• Required attributes: Empty string value

Best practice: Document your protocol's required vs. optional fields so you know which missing values are expected.

Using exported data

In R (statistical analysis)

Network Canvas CSV exports are designed to work seamlessly with R, particularly the egor package:

library(egor)

# Read the exported CSV files
egos <- read.csv("path/to/ego.csv")
alters <- read.csv("path/to/alters_Person.csv")
edges <- read.csv("path/to/edges_friendship.csv")

# Combine them into an egor object, linking the files
# through the Network Canvas identifiers
ego_data <- threefiles_to_egor(
  egos = egos,
  alters.df = alters,
  edges = edges,
  ID.vars = list(
    ego = "networkCanvasEgoUUID",
    alter = "networkCanvasUUID",
    source = "networkCanvasSourceUUID",
    target = "networkCanvasTargetUUID"
  )
)

# Or use the ideanet package, which reads an export folder directly (see tutorial)
library(ideanet)
nc_data <- nc_read(
  path = "path/to/export/folder",
  protocol = "path/to/protocol.netcanvas"
)

If you exported sessions as separate files, combine the matching per-session files (for example with dplyr::bind_rows) before building the egor object, so that each data frame covers all interviews.

See also: Working with Network Canvas Data in R

In Python

Network Canvas CSV exports load directly into pandas, and the per-file identifier columns give you everything needed to join entity files and build graphs with networkx:

import pandas as pd
import networkx as nx

# Read the entity CSVs. Alter and edge rows carry a networkCanvasEgoUUID
# column that links them to their ego's row in the ego file.
egos = pd.read_csv("case_001_session_123_ego.csv")
alters = pd.read_csv("case_001_session_123_attributeList_Person.csv")
edges = pd.read_csv("case_001_session_123_edgeList_Friend.csv")

# A flat analysis table: each alter alongside its ego's attributes
alters_with_ego = alters.merge(egos, on="networkCanvasEgoUUID")

# Build one networkx graph per ego network from the CSV files,
# using the permanent UUID columns as node identifiers
graphs = {}
for ego_uuid, ego_alters in alters.groupby("networkCanvasEgoUUID"):
    G = nx.Graph()
    for _, alter in ego_alters.iterrows():
        G.add_node(alter["networkCanvasUUID"], **alter.to_dict())
    ego_edges = edges[edges["networkCanvasEgoUUID"] == ego_uuid]
    for _, edge in ego_edges.iterrows():
        G.add_edge(
            edge["networkCanvasSourceUUID"],
            edge["networkCanvasTargetUUID"],
            **edge.to_dict(),
        )
    graphs[ego_uuid] = G

Because each session exports its own set of files, a single session's files contain exactly one ego network; the grouping above becomes useful once you concatenate the matching per-session files (for example with pd.concat) into study-level data frames.

Alternatively, read the GraphML file, which contains the complete ego network for a session in one graph. Ego attributes are stored at graph level (declared with for="graph"), so networkx exposes them on the graph's own attribute dictionary:

G = nx.read_graphml("case_001_session_123.graphml")

G.graph              # ego attributes, e.g. {'egoName': 'Enzo', 'egoAge': 40}
G.nodes(data=True)   # alters with their attributes
G.edges(data=True)   # edges with their attributes

In network visualization software

Gephi:

1. Open Gephi
2. File → Open → Select GraphML file
3. Graph displays with all attributes available

UCINET:

1. Import GraphML or CSV
2. Convert to UCINET format if needed
3. Run network analysis procedures

In spreadsheet software

Excel, Google Sheets, LibreOffice Calc:

1. Open CSV files directly
2. Each file opens as a separate spreadsheet
3. Use ego_id to link across files
4. Pivot tables and formulas work with the data

Best practices

During data collection

1. Export frequently: Don't wait until all interviews are complete
2. Test exports early: Export test data to verify format meets your needs
3. Verify data structure: Check that all expected variables appear in exports
4. Document your protocol: Keep notes on variable names and their meanings

File organization

1. Create dedicated folders: Keep exports organized by study, date, or wave
2. Use consistent naming: Develop a naming convention for export folders
3. Version control: Keep track of which protocol version produced which exports
4. Backup regularly: Store exports in multiple locations (local + cloud)

Data integrity

1. Verify counts: Check that the number of participants matches expectations
2. Check for duplicates: Ensure case IDs are unique if intended
3. Validate ranges: Spot-check that variable values are within expected ranges
4. Review metadata: Session times can help identify problematic interviews

Preparing for analysis

1. Export both formats initially: Determine which works best for your workflow
2. Document transformations: Keep notes on any data cleaning or recoding
3. Preserve raw exports: Keep original exports before any modifications
4. Create codebooks: Document variable meanings, especially categorical values

Troubleshooting

Common export issues

Problem: Export button is grayed out

• Cause: No sessions selected
• Solution: Select at least one interview session

Problem: Exported files are empty

• Cause: No data collected for that entity type
• Solution: Verify your protocol collected the expected data; check that interviews were completed

Problem: Can't find exported files

• Cause: Unclear save location
• Solution (Interviewer): Check default Documents folder or recent downloads
• Solution (Fresco): Check browser's download folder

Problem: CSV files won't open in Excel

• Cause: File encoding or comma-separator issues
• Solution: Use "Import Data" feature in Excel instead of double-clicking; specify UTF-8 encoding

Problem: Missing variables in export

• Cause: Variables defined but not used on any stages, or validation prevented completion
• Solution: Verify variables are actually used in protocol; check that forms were completed

Problem: Alter IDs don't match between files

• Cause: Using incrementing alter_id instead of networkCanvasUUID
• Solution: Use networkCanvasUUID for linking across exports; alter_id is export-specific

Data quality checks

After exporting, verify:

1. Record counts match expectations

   • Number of ego records = number of completed interviews
   • Alter counts seem reasonable
   • Edge counts make sense given network size

2. Variable completeness

   • Required fields are populated
   • Optional fields show expected missingness
   • No unexpected missing data patterns

3. Value ranges

   • Categorical variables use expected categories
   • Numerical values within realistic ranges
   • Dates are reasonable

4. Identifier integrity

   • Case IDs are unique (unless repeat interviews intended)
   • UUIDs are present for all entities
   • Ego-alter-edge linkages are valid

Related concepts

• Protocol and Data Workflows - How protocols and data move through each way of running a study
• Interviewer Online and Offline Workflows - Deploying protocols to devices and collecting their data, with or without internet
• Using Fresco - Export data from Fresco-based studies
• Working with Data in R - Detailed tutorial on analyzing Network Canvas data in R
• Variables - Understanding the variables you'll see in exports

Next steps

Now that you understand data export, you can:

1. Export test data from a sample interview to verify format
2. Practice importing exported data into your analysis software
3. Review the Working with Data tutorial for R analysis workflows
4. Plan your data organization strategy for your study
